SMR-1206 - SAMYUNG 6KW/72NM Marine Radar

Lain-Lain - Elektronik

Dijual

Rp126.500.000,-

Provinsi Banten - Kota Tangerang

Baru

SAMYUNG SMR-1206 6KW 72NM Marine Radar
==================================================================
Features
• Applied with 12.1” Panel viewing angle 178
• Optical bonding applied on LCD Display for brightness control during daytime
• Maximum of 20 automatic and 10 manual simultaneous track system
• Able to store 1,000 record of data and display up to 100 data information sent to external AIS equipment
• Able to overlay radar image on the chart for safe voyage
• Due to external direction sensor value of radar and chart image, display image rotates in real-time
• Radar image can be displayed on the monitor with DVI connecting method
• PC mouse (wire/wireless) can be connected to radar equipment for faster and convenient use of cursor movement and target selection
• Radar images can be overlaid on the all NAVIONICS charts
==================================================================
Specifications
SMR-1204/1206
Display Unit: 12-Inch Color LCD, Vertical Display
Resolution: 800 x 600
Indication Type: RASTER SCAN TYPE
Distance Unit: NM/SM (0.0625 – 72NM), KM (0.15 – 32KM)
Display Mode:
• Motional Mode: Relative, True
• Azimuth Mode: Head-Up (Relative), North-Up (Relative, True), Course-Up (Relative, True)
Consumption Power: 60W/85W
Power Supply: DC 12/24V -10% / +30%
Waves/Heavy Rain Clutter: Automatic/Manual
Course Indication: Off, 15s, 30s, 1min, 2min, 3min, 4min, 5min, 6min, 10min, 15min, 30min, 1hr, 2hr, 3hr, 4hr, 5hr, 6hr, 10hr, 12hr, 24hr, Cont.
Input/Output Port: NMEA0183(4 Port), NMEA2000(1 Port)
AIS Track Capacity: 100 Target (marked)/1000 Target (Static Data)
AIS Indication Data: MMSI, Call Sign, Vessel Name, COG, SOG, CPA, TCPA, Bearing, Distance
ARPA Track Capacity: 30 Target
ARPA Indication Data: COG, SOG, CPA, TCPA, Bearing, Distance
EXT. Monitor: DVI Output
NKE-2043 (2 Ft. Antenna)
Type: Dome – Type Antenna
Output Power: 4KW
TX Frequency: 9,410 ±30MHz
Detection Range: 0.0625 ~ 48NM
Revolution: 16 ~ 48RPM
Beam Width: Horizontal 4.0° / Vertical 25°
NKE-2063 (4 Ft. Antenna)
Type: Bar – Type Antenna
Output Power: 6KW
TX Frequency: 9,410 ±30MHz
Detection Range: 0.0625 ~ 72NM
Revolution: 16 ~ 27RPM
Beam Width: Horizontal 2.0° / Vertical 30°
==================================================================
UNTUK MENGHINDARI PENOLAKAN PESANAN ANDA, SILAHKAN BERTANYA MENGENAI STOK DAN HARGA TERUPDATE ATAU BISA MENGHUBUNGI NOMOR TELP BERIKUT:
TELP: 0813.3117.0440
WHATSAPP: 0813.3117.0440
EMAIL: [email protected]
